Mechanical/Electrical

(Metric)

(Imperial)

Swing Over Bed

228 mm

9 in

Longitudinal Travel (Z)

457 mm

18 in

Cross Travel (X)

101 mm

4 in

Weight

120 kg

300 lbs.

+\- 0.0005"

+\- 0.0005"

Spindle Motor

1.5 HP

Spindle Speed Range

70 - 1500 RPM Programmable

Power Requirements

220 volt 1 Phase

Tool Post

4 position

Features

Mechanical

• Rigid High Grade Iron castings with ground bedways capable of machining steel, aluminum, brass, wood and plastics.
• Feed Screw are precision NSK Ball Screws and Ball Nuts.
• Lubrication - One shot metered to deliver the correct amount of oil to each component.
• Fully enclosed with safety switch on door.
• Variable spindle controlled through computer.
• Can be fit manual with 8 position turret and collet chuck.

Software

• The CNC series software is Simultaneous 4 axis Controller Software capable of machining complex curves.
• Runs standard (Fanuc compatible) G an M Codes, Excellion and HPGL files.
• Programs can be generated manually or with CAD/CAM software.
• Distances specified in metric or inch.
• Support for Tool Length offsets (up to 200 tools).
• Travel limit checking.

Minimum PC configuration for RED/CAM Windows controller software to operate on

• 800 MHz Pentium class computer
• 120 MB of hard disk space
• 1.44 MB Floppy Drive
• 4X CD-ROM
• Super VGA color card with 2 MB of video RAM capable of displaying 1024 x 768 resolution or higher
• Windows 98 SE, Window ME, Windows NT, Windows 2000 or Windows XP operating systems
