Features
Mechanical
- Work surface constructed of flat 40
x 160 mm extruded aluminum table plates.
- Heavy cast aluminum side plates
support Y axis and provide increased rigidity for cutting and positioning applications.
- NSK Precision Ball Screws
and Ball Nuts.
- Capable of cutting wood, plastic,
corian, aluminum and other soft materials.
- A variety of spindles and heads can
be provided and mounted.
- Accessories such as
Rotary Table.
Software
- The CNC series software is
simultaneous 4 axis Controller Software capable of machining complex curves.
- Runs standard (Fanuc compatible) G
and M Codes, Excellion and HPGL files.
- Programs can be generated manually
or with CAD/CAM software.
- Distances specified in Metric or
Inch.
- Support for Tool length offset (up
to 200 tools)
- Travel limit checking.
Minimum PC configuration for RED/CAM
Windows controller software to operate on
- 800 MHz Pentium class
computer
- 120 MB of hard disk
space
- 1.44 MB Floppy Drive
- 4X CD-ROM
- Super VGA color card with 2
MB of video RAM capable of displaying 1024 x 768 resolution or higher
- Windows
98 SE, Window ME, Windows NT, Windows 2000 or Windows XP operating systems
|
